Configured for primary control processing and system diagnostics in Mark V turbine control platforms, the GE DS200DCPAG1ABB (DCPA Digital Processor Control Card) provides direct physical/electrical execution.

Hardware Specifications

Parameter Specification
Model DS200DCPAG1ABB
Brand GE Industrial Systems
Origin USA
Weight 0.85 kg
Dimensions Standard Mark V PCB Form Factor
Operating Temp 0 to 60 deg C
Power Consumption 15 W (Nominal backplane load)
Functional Acronym DCPA
Series Mark V
Assembly Type Normal Assembly
Revision Level Revision G1ABB (A-rated primary, B-rated secondary, B-rated artwork)
Redundancy Modes Simplex, Dual, Triple Modular Redundancy (TMR)
Component Profile 17 Integrated Circuits, 24 Resistor Networks, Metal Film Resistors
Interconnect Interface Vertical Pin Connectors (13 to 20 Pins)

Backplane Bus Communication & Firmware Flash Compatibility

The DS200DCPAG1ABB communicates via the high-speed Mark V control backplane bus, managing deterministic data exchanges across dual or triple modular redundancy (TMR) bus topologies. The board architecture incorporates seventeen onboard integrated circuits and twenty-four resistor network arrays designed to maintain execution timing during inter-rack synchronization. System firmware flash compatibility ensures synchronized cycle execution between R, S, and T cores in TMR configurations, eliminating backplane bus latency and bus contention during critical turbine governing cycles. High-density edge connectors maintain backplane bus velocity while suppressing signal distortion across the local distribution bus.

Frequently Asked Questions

Q: How is backplane bus communication established across redundant control cores?

A: The board utilizes vertical pin connectors (13 to 20 pins) along the side and bottom edges to mate directly with the Mark V backplane bus. In TMR configurations, state synchronization data passes deterministically across isolated backplane channels to maintain phase alignment among the three control processors.

Q: What are the primary physical handling considerations for board replacement?

A: Power off the rack backplane before inserting or removing the card to prevent bus disruption. Static-sensitive components, including the seventeen integrated circuits and ceramic/axial capacitors, require ground-strap bonding to prevent electrostatic discharge (ESD) damage during hardware replacement.

Field Installation Guidelines

  1. Ensure complete de-energization of the Mark V rack power distribution bus prior to card insertion or removal.
  2. Wear an ESD grounding wrist strap attached to an unpainted metal chassis earth ground before handling the circuit card.
  3. Align the board with the designated rack card guides and press firmly until all vertical pin connectors (13 to 20 pin arrays) mate completely with the backplane.
  4. Verify that all interconnect cables are secured without exceeding minimum bend radius constraints.
  5. Apply power to the rack and verify that board diagnostics successfully complete self-test validation before placing the system into auto-execution mode.
