Isochronous & Droop Load Sharing Controller

Isochronous & Droop Load Sharing Controller | Woodward 8273-128

Availability: 99 left in stock

Product Overview The Woodward 8273-128 represents the digital evolution of the industry-standard 2301 series, specifically engineered as a 2301D-ST Digital Electronic Load Sharing...

SKU: 8273-128

Manufacturer: Woodward
Product No.: 8273-128
Product Type: Digital Speed Governors
Product Origin: USA
Payment:T/T, Western Union
Weight: 900g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Product Overview

The Woodward 8273-128 represents the digital evolution of the industry-standard 2301 series, specifically engineered as a 2301D-ST Digital Electronic Load Sharing and Speed Control. This microprocessor-based governor regulates the speed of small steam turbines and manages proportional load distribution across multiple generator sets. By supporting both Isochronous and Droop control modes, the 8273-128 ensures system frequency stability during standalone operation or complex utility paralleling. We supply this unit as 100% Brand New original stock to replace aging analog hardware with high-precision digital logic.

Technical Specifications

The 8273-128 utilizes a high-speed digital processor to deliver instantaneous actuator response and precise frequency regulation.

Parameter	Specification
Catalog Number	8273-128
Manufacturer	Woodward
Series	2301D-ST (Digital Steam Turbine)
Input Power	18–40 VDC (24 VDC Nominal)
Speed Range	100 to 10,000 RPM (via MPU)
Control Modes	Isochronous, Droop, Base Load
Input Signals	Magnetic Pickup (MPU), Analog Bias, Load Sensors
Output Signal	0–200 mA Actuator Drive
Operating Temperature	-40°C to +85°C
Dimensions	275 × 190 × 105 mm
Mounting	Panel or Rack Mount (Normal Locations)

Engineering Advantages

Digital Precision Replacement: The 8273-128 eliminates the "drift" associated with aging analog potentiometers. Its digital microprocessor architecture maintains a constant speed setpoint despite fluctuating ambient temperatures or supply voltage variances.
Versatile Load Management: This controller handles complex paralleling tasks. In Isochronous Mode, it maintains constant frequency regardless of load; in Droop Mode, it allows multiple generators to share the load proportionally based on their individual capacities.
Rugged Steam Turbine Optimization: Specifically tuned for the dynamics of steam turbines, the 8273-128 manages the rapid valve adjustments required to stabilize RPM during sudden load shedding or boiler pressure variations.
Extended Environmental Tolerance: With an operating range of -40°C to +85°C, this unit survives in non-climate-controlled marine engine rooms and remote industrial substations where standard PLCs often fail.
Simplified Diagnostics: The digital interface allows technicians to monitor system health and speed parameters with higher resolution than traditional analog gauges, speeding up commissioning and loop-checking.

FAQs

Q: Can the 8273-128 replace an older analog 2301A load sharing control?

A: Yes. The 2301D-ST series provides a digital upgrade path for legacy analog units. However, because it uses digital configuration, you must verify pinout compatibility and set the parameters via Woodward software to match your turbine’s specific dynamic response requirements.

Q: What is the difference between the 8273-128 and the 8273-1001?

A: The 8273-128 is designed for "Normal Mounting Locations" (standard industrial environments). The 8273-1001 is a specialized variant intended for hazardous locations (Zone 2/Class I, Div 2). Always verify your site’s safety classification before installation.

Q: Does this unit require a specific Magnetic Pickup (MPU)?

A: The 8273-128 accepts a wide range of MPU inputs (100 to 10,000 RPM). It functions with most standard Woodward or third-party magnetic pickups that generate a minimum of 1.0 Vrms at the lowest operating speed.

Q: How do I handle the 24VDC power requirement?

A: Ensure your power supply provides a clean 18–40 VDC range. We recommend using a dedicated, fused power source to prevent electrical noise from other high-draw industrial components from affecting the governor's speed-sensing logic.
