TSXP57104M Schneider Electric Unity Processor

TSXP57104M Schneider Electric 192kB Modicon Premium Processor

TSXP57104M Schneider Electric 192kB Modicon Premium Processor

التوفر: 94 متوفر في المخزون

Schneider Electric TSXP57104M Modicon Premium Unity Processor Module The Schneider Electric TSXP57104M, also cataloged as the TSXP57104M Unity Processor, operates...

رمز المنتج: TSXP57104M

Manufacturer: Schneider
Product No.: TSXP57104M
Product Type: CPU Processors
Product Origin: France
Payment:T/T, Western Union
Weight: 450g
Shipping port: Xiamen
Warranty: 12 months

وصف التقييمات

Schneider Electric TSXP57104M Modicon Premium Unity Processor Module

The Schneider Electric TSXP57104M, also cataloged as the TSXP57104M Unity Processor, operates as a dedicated hardware component for logic execution and multi-task control within Modicon Premium platform networks.

Hardware Specifications

Parameter	Specification
Model	TSXP57104M
Brand	Schneider Electric
Origin	France
Weight	0.45 kg
Dimensions	Single-width Premium module size
Operating Temp	0...60 deg C
Power Consumption	1200 mA @ 5 V DC current consumption
Platform	Modicon Premium
Internal Memory	192 kB internal RAM (96 kB data allocation), expandable via PCMCIA up to 4 MB
Instruction Execution Time	0.12 us Boolean, 0.32 us word arithmetic, 1.75...3 us floating point
Discrete I/O Capacity	512 to 1024 I/O points
Analog I/O Capacity	24 to 128 I/O points
Application Channels	Maximum 8 to 16 application-specific channels
Communication Ports	2 x RS485 mini-DIN (19.2...115 kbps)
Rack Capacity	Supports up to 2 racks of 12 slots (options for 4, 6, 8, or 12 slots)
Local Signaling	LEDs for RUN (green), ERR (red), I/O fault (red), TER/AUX activity (yellow)

Backplane Bus Communication Velocity and Firmware Flash Compatibility

The hardware architecture of the TSXP57104M relies on the Modicon Premium backplane bus infrastructure to maintain deterministic logic scanning intervals across all local and remote expansions. Execution timings execute at 3...6 Kinst/ms through specialized task management schedules, which isolate the master task from fast and event-driven tasks. The processor manages synchronous communication module traffic and maintains state consistency across Profinet / EtherNet/IP deterministic networks via native firmware flash compatibility profiles embedded within the Unity hardware matrix.

Frequently Asked Questions

Q: How does the processor handle internal RAM data preservation during a main rack power interruption?

A: The processor utilizes an internal battery backup system to sustain volatile application program data and register maps within the 192 kB internal RAM structure when primary 5 V DC backplane power is lost.

Q: What is the maximum physical rack configuration supported by this specific processor model?

A: The TSXP57104M configuration profile permits a maximum architecture layout of 2 racks containing up to 12 modules each, or a distributed arrangement across 4, 6, or 8 slot backplane options.

Field Installation Guidelines

Isolate all power sources supplying the Modicon Premium rack enclosure before inserting the single-width processor module into the dedicated slot.
Secure the top and bottom chassis locking mechanisms to ensure positive grounding contact with the rear backplane connector pins.
Avoid routing the RS485 mini-DIN serial communication cables in parallel alignment with high-voltage motor or distribution lines to minimize signal cross-talk.
Verify that the PCMCIA memory expansion card, if utilized, is fully seated and mechanically locked before applying power to the unit.
