PIB101C Alstom 3BD91299 Datasheet & Technical Manual

Availability: 99 left in stock

Alstom PIB101C 3BD91299 Analog I/O Power Interface Board The Alstom PIB101C, also cataloged as the 3BD91299 Analog I/O Power Interface...

SKU: PIB101C

Manufacturer: ALSTOM
Product No.: PIB101C
Product Type: Analog I/O Cards
Product Origin: France
Payment:T/T, Western Union
Weight: 280g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Alstom PIB101C 3BD91299 Analog I/O Power Interface Board

The Alstom PIB101C, also cataloged as the 3BD91299 Analog I/O Power Interface Board, operates as a dedicated hardware component for high-resolution analog acquisition and local logic preprocessing within distributed rack or VME-based architecture platforms.

Hardware Specifications

Parameter	Specification
Model	PIB101C
Brand	Alstom
Origin	France
Weight	0.28 kg
Dimensions	Optimized for distributed rack or VME-based architectures
Operating Temp	-20 to +70 deg C
Power Consumption	Integrated power interface circuitry with autonomous management
Onboard CPU	Intel Atom D2550 Dual-Core (1.86 GHz)
System Memory	1 x 204-pin DDR3 SODIMM slot (Up to 4 GB)
Storage Interface	2.5 inch SATA SSD/HDD support and CFast Industrial Media slot
Expansion Interconnect	Mini PCI-E and PC/104-Plus
Watchdog Timer	Integrated hardware watchdog
Cooling	Passive (Heatsink included)

Deterministic Network Layer & Backplane Bus Communication Velocity

The PIB101C integrates an Intel Atom D2550 processor designed to interface directly with backplane bus structures via dual-protocol PC/104-Plus and Mini PCI-E interconnects. High-speed backplane bus communication velocity licences ensure that multi-channel analog datasets are serialized and transmitted to central controllers without inducing transmission lag. The local processing core executes real-time data filtering and diagnostics independently, matching the deterministic network requirements of EtherNet/IP and Profinet environments. Firmware flash compatibility protocols maintain uniform synchronization across the hardware stack, allowing the interface board to execute real-time local logic loops without overloading peripheral communication links.

Frequently Asked Questions

Q: How does the onboard hardware watchdog timer execute fail-safe recovery?

A: The integrated hardware watchdog timer operates on an independent clock signal. Upon detecting a software execution freeze or local processor lockup, it issues a hard reset signal to the board logic, re-initializing the local analog channels to safely prevent unmonitored states.

Q: What are the specific thermal constraints when operating the board at +70 deg C?

A: The board relies on a passive heatsink mechanism for heat dissipation. When operating near the upper boundary of the -20 to +70 deg C range, a minimum continuous airflow must be maintained across the heatsink surface to prevent thermal throttling of the dual-core Intel Atom CPU.

Q: Can the dual storage interfaces be configured for redundant data logging?

A: Yes. The SATA interface and CFast industrial media slot operate on separate physical channels. System configuration allows the segregation of the primary operating system image on the CFast media while executing continuous data logging on the independent SATA SSD to maintain data integrity during write cycles.

Field Installation Guidelines

Mounting and Grounding: Secure the board into the designated slot of the rack structure using standard mounting hardware. Establish a low-impedance electrical connection from the board ground plane to the chassis ground to discharge electrostatic energy and suppress transient voltages.
Cable Routing: Segment all multi-channel analog signal lines from high-voltage AC lines or motor control wiring. Maintain a physical spacing of at least 300 mm to protect the sensitive 3BD91299 power interface circuitry from electromagnetic interference.
Shielding Protocol: Use twisted-pair shielded instrumentation cables for all external analog connections. Connect the cable shield to the industrial enclosure terminal strip at a single point to prevent ground loops from corrupting the high-resolution analog measurements.
