Product Overview

The Yokogawa A1BR4D-05 serves as a specialized Remote I/O (RIO) Bus Repeater Module for CENTUM CS 3000 and CENTUM VP Distributed Control Systems. This module acts as a vital communication bridge, extending the physical distance of the RIO bus to connect field control units with distant I/O nodes. By regenerating and boosting bus signals across 4 dedicated ports, the A1BR4D-05 maintains high-speed data integrity over several kilometers. It eliminates signal attenuation in large-scale facilities, making it a cornerstone for decentralized control in refineries, offshore platforms, and massive chemical complexes.

Condition: 100% Brand New, Original Factory Packaging.

Part Number Breakdown: A1BR4D Series

Yokogawa uses specific suffix codes to define the functional baseline and safety specifications for the A1BR4D series.

A1BR4D: Terminal Board / Bus Repeater for Analog/Remote I/O.
-0: Always 0 (Standard internal designator).
5: Basic hardware type with no explosion protection.
Style S1: Original hardware style baseline ensuring compatibility with standard RIO nests.

Technical Specifications

The A1BR4D-05 facilitates long-range communication while maintaining strict DCS timing protocols.

Parameter	Specification
Primary Function	RIO Bus Signal Extension & Regeneration
Number of Ports	4 RIO Bus Communication Ports
Supported Bus Type	Yokogawa Proprietary Remote I/O Bus
Transmission Distance	Up to several kilometers (Cable dependent)
Power Supply	24 V DC
Accuracy/Integrity	High-fidelity signal regeneration
Operating Temperature	0°C to +50°C
Dimensions	130 × 107.5 × 32.8 mm
Shipping Weight	3.0 kg (Including protective packaging)

Engineering Advantages

Extended Topology Reach: Standard RIO bus segments face physical length limitations due to signal decay. The A1BR4D-05 regenerates these signals, allowing engineers to place I/O nodes kilometers away from the central Control Room without losing communication speed or reliability.
Multi-Port Branching Flexibility: With 4 integrated RIO ports, this module enables star or tree network topologies. This flexibility simplifies cable routing in complex plant layouts, reducing the total volume of copper cabling required and lowering installation costs.
Signal Integrity in Harsh EMI Zones: High-voltage equipment and heavy motors often generate electromagnetic interference (EMI) that disrupts data. The A1BR4D-05 features industrial-grade filtering to strip noise from incoming signals before re-transmitting a "clean" pulse to the next node.
Seamless Legacy Integration: The A1BR4D-05 maintains full backward compatibility with CENTUM CS 3000 systems while remaining a standard component for newer CENTUM VP architectures. This allows plant managers to upgrade remote nodes without replacing the entire RIO infrastructure.

FAQs

Q: Does the A1BR4D-05 process actual I/O signals (like 4-20mA)?

A: No. The A1BR4D-05 is a communication bus repeater. It manages the flow of digital data between the Field Control Unit (FCU) and the I/O modules. You must pair it with signal-processing modules (such as AAI or ADV series) to handle field instrumentation.

Q: What is the maximum distance I can achieve with one repeater?

A: Total distance depends heavily on the cable grade (e.g., specific RIO bus cables) and environmental noise. Generally, a single repeater extends the bus by several kilometers. You can daisy-chain repeaters for even longer distances, provided you adhere to Yokogawa’s bus timing limits.

Q: How do the LED indicators on the front panel assist in troubleshooting?

A: The module includes status LEDs for each port. These indicators immediately alert technicians to signal loss or bus errors on a specific branch, drastically reducing the time required to locate a physical cable break or a faulty remote node.

Q: Can I install this module in a zone with explosive gases?

A: No. The "5" suffix indicates this is a basic type with no explosion protection. For hazardous area installations, you must house the module in an appropriately rated explosion-proof enclosure or select an intrinsically safe variant from the Yokogawa catalog.
