Yokogawa NFTR85-10 CENTUM VP/CS 3000 FIO Subsystem

The Yokogawa NFTR85-10, also cataloged as the Yokogawa NFTR85-10 Terminal Block Unit, operates as a dedicated hardware component for field wiring interface execution within CENTUM VP / CS 3000 FIO platforms. It routes multi-channel physical input and output signals directly between electronic I/O modules and external field equipment via localized terminal architecture.

Hardware Specifications

Parameter Specification
Model NFTR85-10
Brand Yokogawa
Origin Japan
Weight 0.2 kg
Dimensions 114 x 32.6 x 60.5 mm
Operating Temp -20 to +55 deg C
Power Consumption Passive component (No external power required)
Subsystem Compatibility CENTUM VP / CS 3000 FIO
Connector Type MIL connector
Channel Capacity 32 signal points per block
Maximum Voltage 250 VAC / VDC
Current Rating 5 A maximum continuous per common bus
Dielectric Strength 1500 VAC for 1 minute
Insulation Resistance 100 Mohm or greater at 500 VDC
Protection Mechanism Built-in surge absorber

4-20 mA HART Loop Protocol & Channel Isolation

As a standard component within Yokogawa process automation topologies, this interface unit supports the physical propagation of 4-20 mA HART loop protocol parameters without data attenuation. The internal copper traces maintain localized channel-to-channel isolation baselines to counter common-mode noise issues in analog data streams. The integrated surge absorber architecture protects the 32 discrete connection lines from high-voltage transient spikes generated by external inductive loads like solenoids or relays, preventing electrical damage from reaching backplane I/O cards.

Frequently Asked Questions

Q: Does the NFTR85-10 require a distinct external power supply connection?

A: No. The unit functions as a completely passive mechanical and electrical interface board. It handles signal pass-through and localized surge absorption without drawing power from an external source or the subsystem backplane.

Q: What is the mechanical limitation regarding hot-swapping cables via the MIL connector?

A: The MIL connector interface permits rapid connection and disconnection for maintenance. However, individual field wiring circuits must be de-energized prior to disconnecting the multi-core cable to prevent inductive arcing across the pins.

Field Installation Guidelines

  • Direct physical mounting must be executed onto the standard FIO baseplate using the integrated physical chassis retention screws.
  • Maintain a minimum structural clearance around the unit to ensure proper convective airflow within the enclosure and to hold ambient temperatures within the -20 to +55 deg C operating limits.
  • All external multi-core shielded cables must terminate properly at the designated MIL connector port to establish physical contact stability.
  • Grounding conductors must connect to the dedicated shield/earth terminal provided on the assembly using short, low-impedance wires to ensure the built-in surge absorbers dump voltage spikes directly to the plant ground grid.
