Allen-Bradley 1769-OW16 CompactLogix 16-Point Relay Output Module Product Overview The 1769-OW16 is a high-density electromechanical relay expansion module designed for Allen-Bradley CompactLogix...

SKU: 1769-OW16

Manufacturer: Allen Bradley
Product No.: 1769-OW16
Product Type: Relay Output Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 450g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Allen-Bradley 1769-OW16 CompactLogix 16-Point Relay Output Module

Product Overview

The 1769-OW16 is a high-density electromechanical relay expansion module designed for Allen-Bradley CompactLogix and MicroLogix 1500 systems. It features 16 normally open (N.O.) contacts, providing a versatile interface for switching both AC and DC loads. The module is engineered with two isolated groups of eight points, allowing for the simultaneous control of multiple circuits with different voltage potentials or phases. Its mechanical design ensures zero off-state leakage current, which is a critical requirement for safety interlocks, pilot lights, and high-impedance loads that might otherwise be sensitive to solid-state leakage.

Technical Specifications

Module Type: Digital Relay Output Module
Output Points: 16 Normally Open (N.O.) Contacts
Isolation Groups: 2 Groups (8 points per group)
Operating Voltage Range: 5–265V AC / 5–125V DC
Backplane Current Draw: 205 mA @ 5.1V DC / 180 mA @ 24V DC
Max Current per Point: 2.5 A
Max Current per Module: 20.0 A
AC Contact Rating: 1800 VA Make / 180 VA Break @ 120V/240V AC
DC Contact Rating: 28 VA (e.g., 0.22 A @ 125V DC; 1.0 A @ 28V DC)
Signal Delay: 10 ms maximum (On and Off)
Heat Dissipation: 4.75 W (Max)
Power Supply Distance Rating: 8 modules (must be within 8 slots of the power supply)
Wiring Wire Size: 22–14 AWG (Solid) / 22–16 AWG (Stranded)
Dimensions: 118 x 52.5 x 87 mm
Weight: 0.45 kg (1.0 lb)
