Siemens C98043-A1682-L1 SIMODRIVE Control Board

Siemens C98043-A1682-L1 SIMODRIVE DC Converter Control Circuit Board

Availability: 4 left in stock

DescriptionThe Siemens C98043-A1682-L1 is a specialized control circuit board designed for use within the SIMODRIVE DC converter systems. This module,...

SKU: C98043-A1682-L1

Manufacturer: Siemens
Product No.: C98043-A1682-L1
Product Type: Control Circuit Board
Product Origin: Germany
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Description

The Siemens C98043-A1682-L1 is a specialized control circuit board designed for use within the SIMODRIVE DC converter systems. This module, often associated with the 6SE7036-1EE85-1HA0 spare part reference, serves as a critical component for managing control logic and signal processing in industrial motor drive applications. It ensures precise regulation and reliable operation of DC drive equipment in demanding manufacturing environments.

Features

Engineered for SIMODRIVE DC converter control architectures.
Provides stable control signal processing for motor drive regulation.
Integrated galvanic isolation to protect sensitive control circuitry from electrical noise and surges.
Compact PCB design optimized for integration into standard drive control racks.

Technical Specifications

Manufacturer	Siemens
Model / Order Code	C98043-A1682-L1
Associated Spare Model	6SE7036-1EE85-1HA0
Power Supply	24 V DC
Current Consumption	100 to 200 mA
Signal Isolation	Galvanic isolation
Operating Temperature	0 degC to +60 degC
Tariff Code	8537101190

Installation Guidelines

ESD Precautions: Always handle the circuit board using proper electrostatic discharge (ESD) protection, including grounded wrist straps, to prevent damage to sensitive electronic components.
Power Status: Ensure all power to the drive system is disconnected and verified as de-energized before attempting to install or remove the board.
Seating: Ensure the board is fully and firmly seated in its designated slot within the converter housing to maintain reliable electrical contact.
Environment: Maintain the operating environment within the specified 0 to 60 degC range and ensure adequate ventilation to prevent thermal degradation.
Wiring: Route control signal cables away from high-voltage power lines to minimize electromagnetic interference (EMI) and ensure signal integrity.

FAQ

What is the primary function of the C98043-A1682-L1 board?

This board acts as a control module for Siemens SIMODRIVE DC converters, responsible for managing the control logic necessary for the operation and regulation of DC motor drives.

Is this board compatible with the 6SE7036-1EE85-1HA0 unit?

Yes, the C98043-A1682-L1 is identified as a component or spare part associated with the 6SE7036-1EE85-1HA0 converter assembly. Please verify your specific drive configuration before installation.

What are the power requirements for this module?

The module operates on a 24 V DC power supply with a current consumption ranging between 100 mA and 200 mA.
