Woodward MRD1T2HTL6M42 HighPROTEC MRDT4 Series

Configured for precise engine speed control and transformer differential protection in industrial substations, the Woodward MRD1T2HTL6M42 (MRD1T2HTL6M42 Digital Speed Control Module) provides direct physical/electrical execution.

Hardware Specifications

Parameter Specification
Model MRD1T2HTL6M42
Brand Woodward
Origin USA
Weight 1.55 kg
Dimensions 350 x 120 x 50 mm
Operating Temp -25 to +70 deg C
Power Consumption 10 W
Input Voltage 24-250 V DC / 110-240 V AC
CT Inputs Supports 1 A and 5 A current transformers
Voltage Inputs Up to 800 V AC
Digital Inputs 8 configurable DI channels
Digital Outputs 7 relay contacts
Communication Ports 2x Ethernet, 1x RS232, 1x RS485 (Modbus RTU, Ethernet TCP/IP)
Protection Class IP43
Certifications CE, SIL-compliant

Actuator Loop Feedback Response

The module contains specific hardware sub-circuits optimized for actuator loop feedback response and harmonic distortion suppression. Internal processing components execute percentage differential operations paired with harmonic restraint to filter transient transformer inrush currents from true physical faults. The high-speed physical interface continuously reconciles actuator speed loops and input current transformer vectors to ensure deterministic processing execution under fluctuating electrical load profiles.

Frequently Asked Questions

Q: How does the hardware handle current transformer mismatches within the differential zone?

A: The internal processing architecture allows software scaling parameters to adjust for physical CT ratios from 1:1 up to 10000:1, balancing the current vectors prior to executing the differential protection algorithm.

Q: What is the primary function of the dual Ethernet interfaces on this hardware?

A: The dual Ethernet ports facilitate separate, independent physical connections to SCADA and distributed control network structures, allowing concurrent Modbus TCP/IP communication without latency degradation.

Q: Can the internal relay contacts be used for direct high-voltage breaker tripping?

A: The 7 digital output relay contacts are configured to pilot external heavy-duty trip relays or meet specific control loop interlock limits within rated contact capacity thresholds.

Field Installation Guidelines

  • Mounting Protocol: Secure the housing to a standard grounding-compliant DIN-rail or panel cut-out, ensuring the physical layout allows unhindered convection cooling airflow across the integrated heat sink paths.
  • CT Circuit Wiring: Ensure all external current transformer circuits are properly shorted before disconnecting or servicing the primary AC analog input terminal blocks to avoid dangerous high-voltage transients.
  • Shielding Rules: Use twisted, multi-shielded instrumentation cable for all RS485 and low-voltage digital signal pathways, terminating the shield drain wires strictly at the central enclosure earth ground bus.
  • Terminal Screw Tightening: Torque all electrical terminal screws to the manufacturer-specified limits to maintain gas-tight connections and prevent localized thermal stress caused by vibration-induced terminal resistance.
