P0916NK Foxboro I/A Series Datasheet & Technical Manual

Availability: 10 left in stock

Foxboro P0916NK I/A Series Termination Assembly The Foxboro P0916NK, also cataloged as the P0916NK Termination Assembly, operates as a dedicated...

SKU: P0916NK

Manufacturer: Foxboro
Product No.: P0916NK
Product Type: Termination Assemblies
Product Origin: USA
Payment:T/T, Western Union
Weight: 68g
Shipping port: Xiamen
Warranty: 12 months

Description Reviews

Foxboro P0916NK I/A Series Termination Assembly

The Foxboro P0916NK, also cataloged as the P0916NK Termination Assembly, operates as a dedicated hardware component for field transmitter interfacing within I/A Series DCS networks. The module establishes direct point-to-point electrical pathing for high-density analog and mixed physical signals, linking field wiring nodes directly to matching Field Bus Modules. Equipped with a 9-pin to 9-pin male HDLC connector link alongside multi-channel terminal distribution points, the component delivers hardwired cross-connection without active processing delay.

Hardware Specifications

Parameter	Specification
Model	P0916NK
Brand	Foxboro (Schneider Electric)
Origin	United States
Weight	0.15 lbs
Dimensions	5-1/4 inch integrated cable assembly footprint
Operating Temp	-20 to +60 deg C
Power Consumption	Passive (Powered via FBM backplane)
Channel Capacity	Multi-channel variable based on paired FBM
Signal Types	4-20 mA current loops, voltage signals, thermocouples, RTDs
Connection Type	9-pin to 9-pin male HDLC link and screw-clamp terminals (12-22 AWG)
Isolation	Channel-to-channel and channel-to-ground isolation
Mounting	DIN rail or rack base
Storage Temperature	-40 to +85 deg C
Enclosure Rating	IP20 (Cabinet installation required)
Diagnostics	Open-circuit and short-circuit detection via FBM
Certifications	CE, UL, cUL, ATEX compliant

Process Control & DCS Instrument Characteristics

The P0916NK structural design optimizes copper trace distributions to safeguard the 4-20 mA HART loop protocol against high-frequency physical attenuation. Circuit path layouts prevent signal degradation across adjacent processing lines, suppressing cross-talk during concurrent multi-channel operations. Integrated channel-to-channel isolation physical barriers prevent parasitic ground loop currents from injecting noise loops into low-level analog circuits. For temperature instrumentation linkages, the stable termination points minimize thermal gradients, securing baseline uniformity necessary for accurate cold junction compensation (CJC) calculation at the paired FBM processor.

Frequently Asked Questions

Q: Does the short 5-1/4 inch HDLC cable link impact signal impedance limits?

A: No. The physical length is engineered to maintain standard HDLC differential impedance matching rules, preventing transmission reflections across the FBM interface backplane path.

Q: Is the P0916NK termination assembly capable of hot-swap operations under full current loads?

A: The physical terminal layout supports modular hot-swapping. However, field loops must be isolated prior to physical disconnect to avoid transient voltage breakdown across the 9-pin connector terminals.

Q: What is the backplane current draw for the P0916NK module?

A: The hardware contains entirely passive signal routing pathways and draws zero active power from the backplane; all power allocation is dictated by the active pairing Field Bus Module.

Field Installation Guidelines

Physical Mounting and Bend Radius Limits: Secure the assembly to standard 35 mm DIN rails inside a protective, climate-controlled cabinet. Ensure the 5-1/4 inch integrated HDLC cable maintains a bend radius conforming to standard electrical wiring limits to eliminate stress on the 9-pin solder pins.
Shield Grounding Constraints: Instrument cable shields must terminate exclusively at the primary system cabinet ground bar. Do not loop or ground shields at both the terminal block and field instrument housing to prevent ground current paths from corrupting 4-20 mA signals.
Signal Cable Segregation: Run low-voltage analog lines (4-20 mA, RTD, thermocouple paths) through dedicated, isolated wire trunks. Maintain a physical distance of at least 300 mm from high-voltage AC electrical distribution lines to prevent capacitive induction.
Terminal Block Preparation: Strip field conductors to a maximum length of 7 mm prior to insertion into the screw clamps (12-22 AWG). Tighten terminal screws to standard structural industrial limits to guarantee point contact pressure without shearing the conductor threads.
